1.Summary
?
1.1 Working Based on existing GSM/GPRS network and GPS satellites, Set multiple functions of security, tracking, monitoring surveillance, emergency alarms and management?this product can locate and monitor any remote targets by SMS or internet.
?
1.2 Features
1.2.1?Built-in GSM, GPS antenna, compact, elegant appearance.
1.2.2?Support GPS and LBS (Location based service) double tracking solutions.
1.2.3?Support SMS/GPRS/Internet Network data transmission
1.2.4?Support configure the settings remotely
1.2.5?Set multiple functions of security, tracking, monitoring surveillance, emergency alarms and management in its entirety
?
2.Applications
Used widely for vehicle and other moving objects tracking.
?
3.Specifications
|
Content
|
Specification
|
|
DIM
|
9.6?5.3?1.6cm
|
|
Weight
|
70g
|
|
Network
|
GSM/GPRS
|
|
Band
|
850/900/1800/1900Mhz
|
|
GPS sensitivity
|
? ? ? ? ?-159dBm
|
|
GPS accuracy
|
5m
|
|
GPS start time
|
Cold status ?45s
Warm status ?35s
?Hot status ?1s
|
|
Car power supply
|
12 V -24V
|
|
Back up battery
|
Chargeable 3.7V?350mAh Li-ion battery
|
|
Storage Temp
|
-40?C to +85?C
|
|
Operation Temp.
|
-20?C to +65?C
|
|
Humidity
|
5%--95% non-condensing
|
]
